Item number: 180026

SIRAX MT7050 AC/DC Power and tension converter

The SIRAX MT7050 is an all-in-one AC/DC current and voltage converter and is designed for DIN rail mounting. Common current and voltage transformers, Rogowski coils and temperature sensors (PT100 or NTC) can be connected.

They measure RMS AC and DC, average min. and max. Measurement, frequency, crest factor, temperature or resistance measurement, harmonic analysis up to the 63rd, THD, Ipeak and measurement of the internal temperature of the module. The SIRAX MT7000 and MT7050 are equipped with a fully configurable analogue output, a digital output and an RS485 Modbus RTU interface. The free configuration software makes it very easy to program the devices.

Product Highlights

Break-resistant plastic housing made of PBT
Flame retardant and self extinguishing according to UL94 V0
Common current and voltage transformers, Rogowski coils and temperature sensors can be connected
Configuration by configuration software
Serial RS485 Modbus/RTU output
DIN rail or wall mounting for vertical or horizontal position
